DISPLAY	Panel	23.8″
	Physical Resolution	3840*2160
	Aspect Ratio	16:9
	Brightness	300 cd/m²
	Contrast	1000：1
	Viewing Angle	178°/178°（H/V)
	HDR	ST2084 300/1000/10000/HLG
	Supported Log Formats	SLog2 / SLog3 / CLog / NLog / ArriLog / JLog or User…
	Look up Table(LUT)support	3D LUT (.cube format)
	Technology	Calibration to Rec.709 with optional calibration unit
VIDEO INPUT	SDI	2×12G, 2×3G (Supported 4K-SDI Formats Single/Dual/Quad Link)
	SFP	1×12G SFP (Fiber module for optional)
	HDMI	1×HDMI 2.0
VIDEO LOOP OUTPUT	SDI	2×12G, 2×3G (Supported 4K-SDI Formats Single/Dual/Quad Link)
	HDMI	1×HDMI 2.0
SUPPORTED FORMATS	SDI	2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60…
	SFP	2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60…
	HDMI	2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60…
AUDIO IN/OUT (48kHz PCM AUDIO)	SDI	16ch 48kHz 24-bit
	HDMI	8ch 24-bit
	Ear Jack	3.5mm
	Built-in Speakers	2
REMOTE CONTROL	RS422	In/out
	GPI	1
	LAN	1
POWER	Input Voltage	DC 12-24V
	Power Consumption	≤65W (15V)
	Compatible Batteries	V-Lock or Anton Bauer Mount
	Input Voltage(battery)	14.8V nominal
ENVIRONMENT	Operating Temperature	0℃~40℃
	Storage Temperature	-20℃~60℃
OTHER	Dimension(LWD)	567mm × 376.4mm × 45.7mm
	Weight	7.4kg
